ICON 6100


Media Finish: Textured
Media Width: 54"
Roll Length: 45m (Full Roll)
Price:
Sale price£258.95

Description

ICON® TL-6100 is a 153 micron textured clear polymeric vinyl overlaminating film, backed with a solvent- based permanent adhesive system. ICON® TL-6100 provides excellent print protection, UL 410 slip- resistance, and anti-scratch properties. An exceptional choice for floor graphics, pavement graphics, overlays, heavy equipment, industrial equipment, displays, POP/tradeshow graphics, and more!



Recommended Uses

Substance Incorporated recommends the following end uses for ICON® TL-6100:
Floor graphics requiring UL 410 slip resistance and anti-scratch properties.
Protection of graphics subjected to heavy use in construction and industrial applications. Tradeshow and POP displays requiring anti-glare and anti scratch properties. Indoor/outdoor graphics and decals, requiring addtional durability and UV protection.



Performance

ICON® TL-6100
Material 153 micron Polymeric Calendered Vinyl

Colour Clear
Tensile Strength 170N/25mm

Adhesive Solvent-Based Pressure Sensitive Acrylic
Adhesive Thickness 0.038mm +/-10%
Peel Adhesion 23N/25mm from Stainless Steel
Liner Clear 2.0mil Polyester Release Liner

Liner Release 30 grams/25mm

Dimensional Stability 0.5 mm
Application Temp. 10°C to 32°C recommended, test prior to specific application
Temperature Range -40°C to 88°C
Shelf Life 2 years when stored at 21°C and 50% relative humidity
Print Compatability N/A
Graphic Life Outdoor durability up to 5 years, permanent
Chemical Resistence Resists mild acids, mild akalis, solvents, and salts. Excellent resistance to water, including immersion.



Installation

Before applying an overlaminate, allow 24-48 hours for print to dry. Application surface must be free of dust, dirt, debris, grease, and other contaminants. We highly recommend cleaning the installation surface with isopropyl alcohol prior to application. Dry installation is recommended. Please test any application fluid prior to use in production.
