Atlas G25 // Traction Material


Media Finish: Textured
Media Width: 54"
Roll Length: 22.5m
Price:
Sale price£432.21

Description

Atlas G25 is a 635-micron flexible rough textured clear vinyl overlaminate, backed with an optically clear pressure-sensitive acrylic adhesive system, specifically engineered to adhere to print media. Atlas G25 adds a layer of protection to print media designed for optimal traction and control.



Recommended Uses

Substance Incorporated recommends the following end uses for Ultragrip 2000: Added traction and durability for Motocross, ATV, and Off-Road Vehicle graphics. Anti-slip properties for Marine, Watercraft, and Trailer applications. Anti-scratch and anti-slip overlays for durable applications. Heavy-duty UL410 floor graphic overlays with excessive foot/vehicle traffic.



Performance

Ultragrip 2000
Material 635 micron Engineered Calendered Vinyl

Colour Clear
Tensile Strength 456N/25mm

Adhesive Clear Solvent-Based Pressure Sensitive Acrylic
Adhesive Thickness 0.056mm +/- 10%
Peel Adhesion 24N/25mm from Stainless Steel
Liner 90LB Natural Brown PE Coated Layflat Paper

Liner Release 32 grams/25mm

Dimensional Stability 0.8 mm
Application Temp. 5°C to 27°C recommended, test prior to specific application
Temperature Range -53°C to 104°C
Shelf Life 12 months when stored at 21°C and 50% relative humidity
Print Compatability N/A
Graphic Life Outdoor durability up to 3 years, permanent
Chemical Resistence Resists mild acids, mild akalis, solvents, and salts. Excellent resistance to water, including immersion.



Installation

Before applying an overlaminate, allow 24-48 hours for print to dry. Application surface must be free of dust, dirt, debris, grease, and other contaminants. We highly recommend cleaning the installation surface with isopropyl alcohol prior to application. Mild heat may be used during installation to help Ultragrip 2000 conform to irregular surfaces.
